2.7V series large-capacity monomer
Product features

Large capacity of monomer mainly refers to the products with rated


voltage of 2.7v in monomer and the capacity ranges from 650F to 10000F.


HCCCap super capacitor has low internal resistance, long service life and can realize fast charge and discharge.


Since the power density of large capacity supercapacitor energy storage is up to 10 kw/kg,


which is more than 10 times the power density of ordinary battery.

Product technical parameters

This type of monomer can be used in fields requiring large energy, such as hybrid cars, rail transit,



Fan variable propeller system, engineering machinery (such as port crane, petroleum,


mining machinery), micro grid, elevator and so on.

Product application

model

voltage

capacity

Size(mm)

Outlet type

Operating temperature range

HCAP-P 2R7 657

2.7V

650F

φ35x100

stud

-40~+70℃

HCAP-P 2R7 108

2.7V

1000F

φ50x75

stud

-40~+70℃

HCAP-P 2R7 158

2.7V

1500F

φ50x110

stud

-40~+70℃

HCAP-P 2R7 228

2.7V

2200F

φ50x140

stud

-40~+70℃

HCAP-P 2R7 358

2.7V

3500F

φ63x140

stud

-40~+70℃

HCAP-P 2R7 508

2.7V

5000F

φ63x150

stud

-40~+70℃

HCAP-P 2R7 109

2.7V

10000F

φ76x240

stud

-40~+70℃

Note: the above specifications are for reference only. The latest specifications of the company shall prevail.
